Intel® PXA26x Processor Family Developer’s Manual
6-37
Memory Controller
6.7.3
Synchronous Static Memory Timing Diagrams
A three-beat read cycle for SMROM is shown in
.
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
R
eser
ved
SXM
RS
2
R
eser
ved
SXM
RS
0
Reset
0
0
0
0
0
0
1
0
0
0
1
1
0
0
1
0
0
0
0
0
0
0
1
0
0
0
1
1
0
0
1
0
Bits
Name
Description
31
—
Reserved
30:16
SXMRS2
MRS value to be written to Synchronous Static memory requiring an MRS command for
Bank Pair 2
15
—
Reserved
14:0
SXMRS0
MRS value to be written to Synchronous Static Memory requiring an MRS command for
Bank Pair 0
Table 6-17. SXMRS Register Bitmap
