Table 4-26. GAFR1_L Bit Definitions
Physical Address
0x40E0_005C
GAFR1_L
System Integration Unit
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
AF47
AF46
AF45
AF44
AF43
AF42
AF41
AF40
AF39
AF38
AF37
AF36
AF35
AF34
AF33
AF32
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Bits
Name
Description
<31:0>
AF[x]
GPIO PIN ‘X’ ALTERNATE FUNCTION SELECT BITS (where x = 32 through 47):
A bit-pair in this register determines the corresponding GPIO pin’s functionality as one of
the alternate functions that is mapped to it or as a generic GPIO pin.
00 – The corresponding GPIO pin (GPIO[x]) is used as a general purpose I/O.
01 – The corresponding GPIO pin (GPIO[x]) is used for its alternate function 1.
10 – The corresponding GPIO pin (GPIO[x]) is used for its alternate function 2.
11 – The corresponding GPIO pin (GPIO[x]) is used for its alternate function 3.
Table 4-27. GAFR1_U Bit Definitions
Physical Address
0x40E0_0060
GAFR1_U
System Integration Unit
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
AF63
AF62
AF61
AF60
AF59
AF58
AF57
AF56
AF55
FA54
AF53
AF52
AF51
AF50
AF49
AF48
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Bits
Name
Description
<31:0>
AF[x]
GPIO PIN ‘X’ ALTERNATE FUNCTION SELECT BITS (where x = 48 through 63):
A bit-pair in this register determines the corresponding GPIO pin’s functionality as one of
the alternate functions that is mapped to it or as a generic GPIO pin.
00 – The corresponding GPIO pin (GPIO[x]) is used as a general purpose I/O.
01 – The corresponding GPIO pin (GPIO[x]) is used for its alternate function 1.
10 – The corresponding GPIO pin (GPIO[x]) is used for its alternate function 2.
11 – The corresponding GPIO pin (GPIO[x]) is used for its alternate function 3.
