Intel PXA26X - Manual (Page 189)

Intel® PXA26x Processor Family Developer’s Manual 5-31
Direct Memory Access Controller
0x4000 0270 DDADR7 DMA Descriptor Address Register channel 7
0x4000 0274 DSADR7 DMA Source Address Register channel 7
0x4000 0278 DTADR7 DMA Target Address Register channel 7
0x4000 027C DCMD7 DMA Command Address Register channel 7
0x4000 0280 DDADR8 DMA Descriptor Address Register channel 8
0x4000 0284 DSADR8 DMA Source Address Register channel 8
0x4000 0288 DTADR8 DMA Target Address Register channel 8
0x4000 028C DCMD8 DMA Command Address Register channel 8
0x4000 0290 DDADR9 DMA Descriptor Address Register channel 9
0x4000 0294 DSADR9 DMA Source Address Register channel 9
0x4000 0298 DTADR9 DMA Target Address Register channel 9
0x4000 029C DCMD9 DMA Command Address Register channel 9
0x4000 02A0 DDADR10 DMA Descriptor Address Register channel 10
0x4000 02A4 DSADR10 DMA Source Address Register channel 10
0x4000 02A8 DTADR10 DMA Target Address Register channel 10
0x4000 02AC DCMD10 DMA Command Address Register channel 10
0x4000 02B0 DDADR11 DMA Descriptor Address Register channel 11
0x4000 02B4 DSADR11 DMA Source Address Register channel 11
0x4000 02B8 DTADR11 DMA Target Address Register channel 11
0x4000 02BC DCMD11 DMA Command Address Register channel 11
0x4000 02C0 DDADR12 DMA Descriptor Address Register channel 12
0x4000 02C4 DSADR12 DMA Source Address Register channel 12
0x4000 02C8 DTADR12 DMA Target Address Register channel 12
0x4000 02CC DCMD12 DMA Command Address Register channel 12
0x4000 02D0 DDADR13 DMA Descriptor Address Register channel 13
0x4000 02D4 DSADR13 DMA Source Address Register channel 13
0x4000 02D8 DTADR13 DMA Target Address Register channel 13
0x4000 02DC DCMD13 DMA Command Address Register channel 13
0x4000 02E0 DDADR14 DMA Descriptor Address Register channel 14
0x4000 02E4 DSADR14 DMA Source Address Register channel 14
0x4000 02E8 DTADR14 DMA Target Address Register channel 14
0x4000 02EC DCMD14 DMA Command Address Register channel 14
0x4000 02F0 DDADR15 DMA Descriptor Address Register channel 15
0x4000 02F4 DSADR15 DMA Source Address Register channel 15
0x4000 02F8 DTADR15 DMA Target Address Register channel 15
0x4000 02FC DCMD15 DMA Command Address Register channel 15
Table 5-13. DMA Controller Registers (Sheet 4 of 4)
Address Name Description
