Intel® PXA26x Processor Family Developer’s Manual
12-37
Universal Serial Bus Device Controller
12.6.7.8
Transmit Short Packet (TSP)
Software uses the transmit short to indicate that the last byte of a data transfer has been sent to the
FIFO. This indicates to the UDC that a short packet or zero-sized packet is ready to transmit.
Software must not set this bit if a packet of 8 bytes is to be transmitted. When the data packet is
successfully transmitted, the UDC clears this bit.
12.6.8
UDC Interrupt Control Register 0 (UICR0)
The UICR0 contains 8 control bits to enable/disable interrupt service requests from data endpoints
0 - 7. All of the UICR0 bits are reset to a 1 so interrupts are not generated on initial system reset.
Table 12-18. UDC Endpoint x Control Status Register, Where x is 5, 10, or 15
0h 4060 0024
UDCCS5
Read/Write
0h 4060 0038
UDCCS10
Read/Write
0h 4060 004C
UDCCS15
Read/Write
Bit
31:8
7
6
5
4
3
2
1
0
Reserved
TSP
Reserved
FST
SST
TUR
FTF
TPC
TFS
Rese
t
X
0
0
0
0
0
0
0
1
Bits
Name
Description
0
TFS
TRANSMIT FIFO SERVICE (read-only):
0 – Transmit FIFO has no room for new data
1 – Transmit FIFO has room for 1 complete data packet
1
TPC
TRANSMIT PACKET COMPLETE (read/write 1 to clear):
0 – Error/status bits invalid.
1 – Transmit packet has been sent and error/status bits are valid.
2
FTF
FLUSH Tx FIFO (always read 0/ write a 1 to set):
1 – Flush Contents of TX FIFO
3
TUR
TRANSMIT FIFO UNDERRUN (read/write 1 to clear):
1 – Transmit FIFO experienced an underrun.
4
SST
SENT STALL (read/write 1 to clear):
1 – STALL handshake was sent.
5
FST
FORCE STALL (read/write):
1 – Issue STALL handshakes to IN tokens.
6
—
Reserved
Always reads 0
7
TSP
TRANSMIT SHORT PACKET (read/write 1 to set):
1 – Short packet ready for transmission.
31:8
—
Reserved for future Use
