Intel® PXA26x Processor Family Developer’s Manual
5-13
Direct Memory Access Controller
1. The DMAC transfers the required number of bytes from the I/O device addressed by
DSADRx[31:0] to the DMAC write buffer.
2. The DMAC transfers the data to the memory controller via the internal bus. DCMD[WIDTH]
specifies the width of the internal peripheral to which the transfer is being made.
3. At the end of the transfer, DTADRx is increased by the smaller value of DCMDx[LENGTH]
and DCMD[SIZE]. DCMDx[LENGTH] is decreased by the same number.
For a flow-through DMA write to an internal peripheral, use these settings for the DMAC register
bits:
•
DSADR[SRCADDR] = internal peripheral address
•
DTADR[TRGADDR] = external memory address
•
DCMD[INCTRGADDR] = 1
•
DCMD[FLOWSRC] = 1
•
DCMD[FLOWTRG] = 0
5.2.2
Quick Reference for Direct Memory Access Programming
as a quick reference sheet for programming the DMA.
Table 5-5. DMA Quick Reference for Internal Peripherals (Sheet 1 of 2)
Unit
Function
FIFO Address
Width
(bytes)
DCMD.
Width
(binary)
Burst Size
(bytes)
Source
or
Target
DRCMR
I2S
receive
0x40400080
4
11
8, 16, 32
Source
0x4000 0108
transmit
0x40400080
4
11
8, 16, 32
Target
0x4000 010c
BTUART
receive
0x40200000
1
01
8, 16, 32
Source
0x4000 0110
transmit
0x40200000
1
01
8, 16, 32 or
trailing
Target
0x4000 0114
FFUART
receive
0x40100000
1
01
8, 16, 32
Source
0x4000 0118
transmit
0x40100000
1
01
8, 16, 32 or
trailing
Target
0x4000 011c
AC97
microphone
0x40500060
4
11
8, 16, 32
Source
0x4000 0120
modem
receive
0x40500140
4
11
8, 16, 32
Source
0x4000 0124
modem
transmit
0x40500140
4
11
8, 16, 32
Target
0x4000 0128
audio receive
0x40500040
4
11
8, 16, 32
Source
0x4000 012c
audio transmit
0x40500040
4
11
8, 16, 32
Target
0x4000 0130
SSP
receive
0x41000010
2
10
8, 16
Source
0x4000 0134
transmit
0x41000010
2
10
8, 16
Target
0x4000 0138
FICP
receive
0x4080000C
1
01
8, 16, 32
Source
0x4000 0144
transmit 0x4080000C
1
01
8, 16, 32 or
trailing
Target
0x4000 0148
