The external frame buffer is an off-chip memory area used to supply enough encoded pixel values to fill
the entire screen one or more times. The number of pixel data values depends on the size of the
screen (for example, 640x480=307,200 encoded pixel values).
show the memory organization within the frame buffer for each size pixel encoding.
In the following figures, base refers to the initial address programmed in FSADR, palette buffer
index refers to the data that specifies the location in the palette buffer, and raw pixel data refers to
the actual 16-bit RGB data when the palette RAM is bypassed.
Figure 7-5. Palette-Buffer Format
Individual Palette Entry
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Color
Red (R)
Green (G)
Blue (B)
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Mono
unused
Monochrome (M)
Little Endian Palette Entry Ordering
4-, 16- or 256-Entry Palette Buffer
Bit
31
16
15
0
Base
+ 0x0
Palette entry 1
Palette entry 0
Base
+ 0x4
Palette entry 3
Palette entry 2
Entries 4 through 255 do not exist for 1 and 2
bits/pixel.
Base
+
0x1C
Palette entry 15
Palette entry 14
Base
+
0x20
Palette entry 17
Palette entry 16
Entries 16 through 255 do not exist for 1,
2, and 4 bits/pixel.
Base
+
0x1F
C
Palette entry 255
Palette entry 254
Figure 7-6. 1-Bit Per Pixel Data Memory Organization
Bit
0
1 bit/pixel
Palette Buffer Index[0]
