Intel® PXA26x Processor Family Developer’s Manual 10-1
Universal Asynchronous Receiver/
Transmitter
10
This chapter describes the three universal asynchronous receiver/transmitter (UART) serial ports
without hardware flow control. Because the Hardware UART is configured differently than the
other three, it is described in
Section 17, “Hardware UART” . The serial ports are controlled via
direct memory access (DMA) or programmed I/O. This section describes the full function UART,
Bluetooth UART, and standard UART. These UARTS use the same programming model.
10.1 Feature List
The UARTs share these features:
• Functionally compatible with the 16550
• Ability to add or delete standard asynchronous communications bits (start, stop, and parity) in
the serial data
• Independently controlled transmit, receive, line status, and data set interrupts
• Programmable baud rate generator that allows the internal clock to be divided by 1 to 2
16
–1 to
generate an internal 16X clock
• Modem control pins that allow flow control through software. Each UART has different
modem control capability.
• Fully programmable serial-interface:
— 5-, 6-, 7-, or 8-bit characters
— Even, odd, and no parity detection
— 1, 1.5, or 2 stop bit generation
— Baud rate generation up to 921.6 Kbps
• 64-byte transmit FIFO
• 64-byte receive FIFO
• Complete status reporting capability
• Ability to generate and detect line breaks
• Internal diagnostic capabilities that include:
— Loopback controls for communications link fault isolation
— Break, parity, and framing error simulation
• Fully prioritized interrupt system controls
• Separate DMA requests for transmit and receive data services
• Slow infrared asynchronous interface that conforms to the Infrared Data Association (IrDA)
standard
