11-16

Intel® PXA26x Processor Family Developer’s Manual

Fast Infrared Communication Port

11.4

Fast Infrared Communications Port Register
Locations

shows the registers associated with the FICP block and the physical addresses used to

access them.

Table 11-8. FICP Control, Data, and Status Register Locations

Address

Name

Description

0x4080_0000

ICCR0

FICP Control Register 0

0x4080_0004

ICCR1

FICP Control Register 1

0x4080_0008

ICCR2

FICP Control Register 2

0x4080_000C

ICDR

FICP Data Register

0x4080_0010

—

Reserved

0x4080_0014

ICSR0

FICP Status Register 0

0x4080_0018

ICSR1
