6.3 Recall Results
Selecting RECALL RESULTS from the Main Menu invokes the RECALL SETUP screen. Users can recall
saved results from non-volatile memory or from USB memory. See Section 5.3.2 for more information.
6.4 The System Setup Menu
Selecting the Wrench ( ) option from the MAIN MENU (see Section 6) displays the SYSTEM
SETUP menu and it enables the user to set global system parameters such as Date, Time, Baud Rate and
Keyboard Backlight options. There is also a Yes/No selection for the Keyboard Beeper.
EDIT /
SELECT OPTIONS INIT
MODEM MAIN
MENU
Dat e (yyyymmd d):
Time (hhmmss):
Baud R ate:
Parity:
Flow Control:
Mode m Init. String:
Set Factory Def aults:
Auto Shu t Off (min):
Live Sign al Thr (dBm):
Measurement Standa rd:
Distance Units:
Wire Size:
Lang uage:
IP Ad dress:
Subnet Mask:
Gatewa y:
Externa l C ap. De tection:
Rem ote De vice:
VisiSHARK En able :
0923 49
3840 0
NONE
NONE
ATQ1E0S0=1
No
0
-3 0
ITU
Feet
AWG
English
192.1 68. 1. 6 6
255.2 55.255.25 5
0. 0. 0. 0
Yes
NONE
Yes
E F CHG
SYSTEM SETUP
2001 0423
SYSTEM
CONFIG. UPGRADE
SOFTWAR E
Figure 6.4A – The System Setup Menu
Date: To change the Date setting, use the Arrow Keys to move the cursor so that the current
Date value is highlighted. Use the Alphanumeric Keypad to enter the desired value.
The format is yyyymmdd meaning 4 digit year followed by the 2 digit numerical
representation of the month (i.e. January = 01, February = 02, etc), and followed by
the date (2 digits). Press ENTER when the value is correctly entered to save your
changes. More parameters can be changed at this point, or press MAIN MENU to
