EXFO CableSHARK P3 VF/DSL Cable Qualifier User Manual
Page 148
VF / DSL Cable Qualifier
136
SELECT PREVIOUS
Pressing the function button corresponding to SELECT PREVIOUS scrolls
backward through each of the parameters that are available for the highlighted
option.
SELECT NEXT
Pressing the function button corresponding to SELECT NEXT scrolls forward
through each of the parameters that are available for the highlighted option.
CABLE TESTS
Pressing the function button corresponding to CABLE TESTS causes the
CABLE TESTS pop-up window to appear.
MAIN MENU
Select the function button corresponding to MAIN MENU to return to the Main
Menu.
8.7.2 Running a DMM Test
Use caution when connecting the test set, as telephone cables may have dangerous A.C. or D.C.
voltages on them.
Press the function button corresponding to the RUN / STOP button on the front of the CableSHARK to
initiate or stop the test. Figure 8.7.2A shows an example of the results obtained from a partial AUTOTEST-
12 DMM Test that has been run on the same circuit. Autotest can be completed in less than 15 seconds.
