CableSHARK P3 User Guide
109
EDIT /
SELECT MAIN
MENU
Test Type :
Term Impedance :
Termination:
Noise Filter :
Imp Nse Threshold:
Imp Nse Meas Time:
Measurement Units:
100 OHMS
TERMINATED
NO FILTER
43
dBm
1 Minute
E F CHG
IMPULSE NOISE
WARNING
Note: telephone cables may have dangerous A.C. or D.C.
voltages on them, therefore caution should be taken when
connecting this test set.
!
SELECT
NEXT
-
F IGURE 8.4.1C – I MPULSE N OISE T EST S ETUP M ENU
