EXFO CableSHARK P3 VF/DSL Cable Qualifier - Manual (Page 213)

CableSHARK P3 User Guide
201
Table 12.3.1
Loop Resistance @ 68°F or 20°C
Wire Gauge Resistance
mm AWG Ω
/km
Ω
/kft
Ω
/mi
0.32 PE 28 409 125 658
0.40 PE 280 84.4 451
26 PIC 273 83.1 439
0.50 PE 179 54.5 288
24 PIC 172 52.3 276
0.60 PE 123 37.5 198
0.63 PE 113 34.5 182
22 PIC 108 32.9 174
0.80 PE 69 21.0 111
0.90 PE 55 16.8 88.5
19 PIC 53.8 16.4 86.6
NOTES:
PE = metric Polyethylene insulated cable
PIC = AWG Polyethylene insulated cable
Metric & AWG Wire Gauges: R & C (0Hz/DC, 20 °C or 68°F)
10. For a resistance at a temperature other than 68°F or 20°C, use the following formula. Note that
these calculations are for copper cabling only.
For temperatures in Fahrenheit:
R
TF
= R
68°F
+ [ 0.0022 * ( T
F
- 68°F ) * R
68°F
]
Where R
TF
= new resistance based on new temperature in Fahrenheit
T
F
= new temperature
R
68°F
= resistance of the cable @ 68°F
