CableSHARK P3 User Guide
23
positioned to the inside of the battery compartment. In some CableSHARK’s, this may require some
maneuvering to position the connector in place. The excess battery wire should be carefully inserted into the
side slot of the battery compartment. Install the battery in the compartment; replace the battery cover and
tighten the two slotted screws in place.
Return the old battery to EXFO for recycling. Immediately, (same day) plug the CableSHARK into the mains
so that the battery will be charged. The power LED should be green at this time. Charge the unit until fully
charged.
4.2.3 The LED Power Status Indicator
The CableSHARK’s dual color Power Status LED is designed to indicate the instrument's power status:
State Explanation
Bright Green Running on mains power, the battery is fully charged
Dull Green Running on the battery
Flashing Green The battery is charging
Red The battery is exhausted or there is a malfunction in the battery
Note: The LED can also illuminate so it is orange in colour.
Orange Both the red and green LED’s will illuminate (looks orange) to indicate
the unit is in Responder mode.
