EXFO CableSHARK P3 VF/DSL Cable Qualifier User Manual
Page 253
CableSHARK P3 User Guide
241
F
IGURE
16.3.1B–
K-T
EST
,
C
ONNECTING THE
S
TRAP
16.3.2 Setting up Cable Characteristics
The CableSHARK’s K-test needs to be configured in detail now that the faulty wires have been identified and
the strap is properly attached at the far end.
The following screen is displayed.
IMPORTANT: Follow the CableSHARK’s instructions for the correct Strap configuration.
An improperly connected strap will force the K-Test test to give misleading results.
