CableSHARK P3 User Guide
265
ITU-T Annex B / ISDN, ETSI Full Rate / ISDN
Bits/bin setting: 8 – 15 bits per bin.
14 is default for full rate ADSL
8 is default for G.Lite
Noise margin range: AUTO-CPE, AUTO-CO/EXCH, 0 to 32 dB in 1 dB steps
Frequency range: 4.3 kHz to 1.104 MHz
Frequency accuracy:
± 50 ppm
DMT tone & noise accuracy:
± 0.5 dB
Level resolution: 0.1 dB
Horizontal scale: 0 - 1.104 MHz
Vertical scale: -36 dBm/Hz to -156 dBm/Hz
Bits/bin vertical scale: 0 to 15 bits
Noise filters: None or E, F, G (IEEE-743 / 1995)
Single End ADSL, ADSL2, ADSL2+ (DMT) Test
Extrapolated Results - Combined Frequency Response, PSD Noise / Crosstalk, Signal-to-Noise Ratio,
Disturber Identification, and Data Rate Estimation test plot with cursor and zoom.
The Single-Ended DMT test used by the EXFO CableSHARK is patent pending.
ADSL Data Rate Prediction (Single End):
US Patent Pending # 10/133,408
Distance
range: 300 ft to 16000 ft (100 m to 5000 m)
** range will depend on cable type and condition
** specifications based on 24 AWG (0.5 PE mm) cabling
ADSL test type: Test from CO and test from CPE
ADSL2 test type: Test from CO and test from CPE
ADSL2+ test type: Test from CO and test from CPE
ADSL evaluation: ASI Full Rate/POTS, G.LITE/POTS, ITU-T Annex A / POTS,
ETSI Full Rate / POTS, ITU-T Annex B / ISDN, ETSI Full Rate / ISDN
ADSL2/2+ evaluation: ITU-T Annex A/POTS, ITU-T Annex B/ISDN, ITU-T Annex I/POTS, ITU-T Annex
J/ISDN, ITU-T
Annex L/M/POTS
Bits/bin setting:
8 – 15 bits per bin.
14 is default for full rate ADSL
8 is default for G.Lite
Noise margin range: Auto or 0 to 32 dB in 1 dB steps
Frequency range: ADSL: 4.3 kHz to 1.104 MHz
ADSL2: 4.3 kHz to 1.104 MHz
