VF / DSL Cable Qualifier
22
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with same
or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacture’s instructions.
Charging:
It is recommended that charging of the battery be performed between 0 to +40 0 C.
Storage and Self-discharge: It is recommended that storage of the battery is done between –10 to +50 0 C.
Long-term storage has no permanent effect on battery capacity. Losses in capacity due to self-discharge
are reversible. After Long-term storage (e.g. more than one year at room temperature) up to three full cycles
may be necessary to obtain full capacity.
Repeated charging, operating and storage in extreme temperatures may effect battery life.
NOTE: Should the battery be subjected to a deep discharge, the unit may have to be
plugged in to AC mains for about 2 minutes before the unit can be turned on.
4.2.2.1 Replacing the CableSHARK’S Internal Battery
The Battery is user-replaceable without the need for re-calibration. Extra batteries are available from your
EXFO representative (CSK-BATT2). Accompanying the battery will be instructions for replacing and
charging. The CableSHARK has been designed such that the user can change the battery easily with very
few tools. Extra batteries are available from your EXFO representative. To change the battery, locate the
battery compartment door on the underside of the unit.
Please note that any stored data in non-volatile RAM will not be lost by changing the
rechargeable battery.
After removing the two slotted screws from the battery cover, the cover must be carefully pried; with the
slotted screwdriver ; to loosen and release the sealing tape between the cover and the battery. Note: The
battery is friction fitted into the battery compartment. Once the battery cover has been removed, the battery
can be removed from the battery compartment by placing ones hand over the battery, turning the unit so the
display is facing upwards and then gently tap the CableSHARK against the same hand. Once the battery is
freed from its compartment, the black connector with the flying clip must be removed from the small slot in
the battery compartment. The black clip is then pressed to release the male and female connector.
To reinstall the battery, the mating connectors are latched in place with the retaining clip. Carefully insert the
black connector into the side slot of the battery compartment on a 45 degree angle with the mating clip
