CableSHARK P3 User Guide
215
of each of the function button options: Pressing the SAVE / UPLOAD button shows a pop-up window where
the user is allowed to upload results, and save results to internal memory or to external USB memory.
UPLOAD RESULT Choosing UPLOAD RESULT from the SAVE / UPLOAD pop-up menu sends
the result that appears on the CableSHARK screen (current test or recalled
test) to a PC via a NULL modem cable. The remote control program Visi-
SHARK can be used to capture and analyze the results on a PC.
SAVE TO MEM Choosing SAVE TO MEM from the SAVE / UPLOAD pop-up menu invokes the
SAVE SESSION menu. From here, the test results can be saved to internal
non-volatile memory. See Section 5.3 for more information.
SAVE TO USB Choosing SAVE TO USB from the SAVE / UPLOAD pop-up menu invokes the
SAVE SESSION menu. From here, the test results can be saved to external
USB memory. See Section 5.3 for more information.
The remainder of the buttons are as follows:
PREVIOUS SCREEN Pressing the function button associated with PREVIOUS SCREEN returns the
user to the Ringer Detection test setup screen.
MAIN MENU Select MAIN MENU to return to the Main Menu.
