EXFO CableSHARK P3 VF/DSL Cable Qualifier User Manual
Page 174
VF / DSL Cable Qualifier
162
MAIN
MENU
E
F
CHG
EDIT/
SELECT
Name:
DATU
milliwatt source
DELETE
RECORD
Tel. Number
4165551212
18005551212
milliwatt source
18005551212
CABLE
TESTS
F
IGURE
8.11.1.3C
–
P
HONE
B
OOK
• Pressing the EDIT/SELECT key allows a user to modify a highlighted
name/number
• Pressing the ADD NEW RECORD key allows a user to add a new
name/number to the Phone Book
• Pressing the DELETE RECORD key allows a user to delete a
highlighted entry
• Pressing the PREVIOUS SCREEN key returns the user to the VF
AUTO TEST SETUP screen
SELECT PREVIOUS
Pressing the function button corresponding to SELECT PREVIOUS scrolls
backward through each of the parameters that are available for the highlighted
option.
SELECT NEXT
Pressing the function button corresponding to SELECT NEXT scrolls forward
through each of the parameters that are available for the highlighted option.
DEFAULT VALUES
Sets the ADSL AUTO TEST parameters to their factory defaults.
ADSL SETUP
Allows the user to setup the ADSL Auto Test
