SAVE TO USB Choosing SAVE TO USB from the SAVE / UPLOAD pop-up menu invokes the
SAVE SESSION menu. From here, the test results can be saved to external
USB memory. See Section 5.3 for more information.
The remainder of the buttons are as follows:
VIEW SETUP This function allows users to view the pass/fail thresholds used for the automatic tests.
TEST SETUP Pressing the function button associated with TEST SETUP activates the AUTO Test
Setup menu. Test parameters can be modified and the test can be run once again from
this screen.
MAIN MENU Select MAIN MENU to return to the Main Menu.
8.11.4 Running an SHDSL AUTO Test
Use caution when connecting the test set, as telephone cables may have dangerous A.C. or D.C.
voltages on them.
NOTE: SHDSL AUTO Test will only be available if the SHDSL option has been purchased.
Please contact your local EXFO representative for further information and to purchase this
option.
NOTE: The Automatic tests use the currently set parameters for the tests it runs. Please review the
setup for each test by going to that tests setup menu before continuing with the Auto-Test.
From the Main Menu, press the AUTO TESTS function button (F2) to access the AUTO TEST MENU. Start
the
SHDSL AUTO test by pressing F6. The CableSHARK will perform a DMM test (Voltage, Resistance,
Capacitance), a Load Coil Test, a TDR, a Longitudinal Balance test, Capacitive Imbalance and a Single End
SHDSL test. Results are presented in both a text format as well as a graphical format.
