VF / DSL Cable Qualifier
236
MAIN
MENU
E F CHG
dBrn
Frequency
540 Hz
480 Hz
420 Hz
360 Hz
300 Hz
240 Hz
180 Hz
120 Hz
60 Hz
FREEZE
C-Message noise
3 kHz Flat Noise
=
=
87 dBrnC
50 dBrnC
Voltage
0.0 V
0.1 V
0.0 V
0.0 V
0.0 V
0.1 V
0.1 V
0.1 V
0.4 V
Level
65 dBrn
70
65
65
65
75
80
80
87
dBrn
dBrn
dBrn
dBrn
dBrn
dBrn
dBrn
dBrn
50 70 90 110 130
F IGURE 15.5B - R UNNING THE P OWER I NFLUENCE TEST
Press the FREEZE button or the RUN/STOP key to stop the test. Results can be saved by pressing the
SAVE/UPLOAD button.
