CableSHARK P3 User Guide
249
A.2 Attenuation Responses
The following graphs depict Attenuation responses to CSA, Extended CSA, Mid-CSA, and ANSI loop
topologies (curve = calculated attenuation of ideal cable). These graphs represent the loop topologies
outlined in Appendix A.1
CSA Loop #1
CSA Loop #2
CSA Loop #4
CSA Loop #5
