VF / DSL Cable Qualifier
42
value is correctly selected to save any changes. More parameters can be
changed at this point, or press MAIN MENU to return to the Main Menu.
SELECT NEXT For parameters that are preset in the CableSHARK (i.e. Baud Rate), the user can
press the function key related to SELECT NEXT to step forwards through the
available options for a specific highlighted parameter. Press ENTER when the
value is correctly selected to save any changes. More parameters can be
changed at this point, or press MAIN MENU to return to the Main Menu.
6.1 The Cable Test Menu
Selecting the Cable Tests option displays the CABLE TESTS pop-up menu and sub-menu. From this first
pop-up menu, the user can select from the variety of cable tests available from the CableSHARK, including
FREQUENCY RESPONSE, TDR, PSD NOISE, and LOAD COIL DETECTION. The sub-menu is available
to some cable tests and allows the user to more easily select the desired test that they would like to run.
Simply use the arrow keys to select the test and press the RUN/STOP key.
E F MAIN MENU
CableSHARK P3
ENTER
13:16:20
Copyright Consultronic s Lim ited 2000 - 2006
Software Version 3.86
C ANCEL CLOSE
* AUTOTEST-14 (V,R,C,I)
AUTOTEST-12 (V,R,C)
VOLTAGE (V)
RESISTANCE (R)
CAPACITANCE (C)
CURRENT (I) DIGITAL MULTIMETER TESTS
DMT
FREQUENCY RESPONSE
TDR
FDR
NOISE
LONGITUDINAL BALANCE
LOAD COIL
SPECTRAL DETECTIVE
RETURN LOSS
SHDSL
RESISTANCE FAULT LOCATOR
K-TEST
4 WIRE XTALK
ISOLATION
GROUND RESISTANCE
VF TESTS
RINGER DETECTION
CABLE T ESTS
DIGITAL MULTIMETER TESTS
Figure 6.1A – The Cable Tests Pop-Up Menu
