VF / DSL Cable Qualifier
264
End-to-End Frequency Response
Plot with cursor and zoom
Distance
range: 300 ft to 45000 ft (100 m to 13,500 m)
** range will depend on cable type and condition
** specifications based on 24 AWG (0.5 PE mm) cabling
Frequency range: 4.3 kHz to 2.0 MHz (2.2 MHz or 6 MHz not supported)
Frequency accuracy:
± 50 ppm
Accuracy:
± 0.5 dB
Resolution: 0.1 dB
Horizontal scale: ISDN 500 kHz, HDSL 1 MHz, ADSL 2.2 MHz
Vertical scale: 0 to +90 dB
Load Coil Detection
Can detect up to 6 load coils
Test methodology:
End-to-End, Single-End (plot to 10 kHz)
Distance range: U p to 24,000 ft (up to 7,500 m)
** range will depend on cable type and condition
** specifications based on 24 AWG (0.5 PE mm) cabling
End-to-End DMT Test
Combined Frequency Response, PSD Noise / Crosstalk, Signal-to-Noise Ratio, Disturber Identification and
Data Rate Estimation test plot with cursor and zoom.
The End-to-End DMT test used by the EXFO CableSHARK is patent protected.
ADSL Data Rate Prediction (End to End):
US Patent # US 6,445,773 B1 Sep 3, 2002
Distance range:
300 ft to 45000 ft (100 m to 14000 m)
** range will depend on cable type and condition
** specifications based on 24 AWG (0.5 PE mm) cabling
Test resolution: Coarse, Fine
ADSL setups: ANSI Full Rate/POTS, ITU-T Annex A / POTS
ETSI Full Rate / POTS, G.LITE/POTS
