CableSHARK P3 User Guide
193
If the pair does not have a fault on it, the CableSHARK will display the following message:
CONGRATULATIONS
!
F
IGURE
12.1.1.5A
–
N
O
F
AULT
D
ETECTED
If there is a small voltage on the line and there is a resistive fault, this is likely a battery cross situation. The
RFL test will indicate the following:
Yellow
Blue Green
MAIN
MENU
E
CHG
WARNING
Connect a good pair to Yellow and Blue.
Connect far end strap from wire connected to Black
to both ends of good pair.
!
F
Black
Red Green
CABLE
TESTS
Battery Cross fault detected on TIP, 5.9 Mohms, CO Voltage -48.0V
Battery Cross fault detected on TIP, 5.9 Mohms
Yellow
Blue Green
F
IGURE
12.1.1.5C
–
RFL
M
ESSAGE INDICATING PLACEMENT OF
S
TRAP
Connect the strap (see Section 12.1.1.6) as indicated and press the CONTINUE button.
