AT-S62 Management Software Web Browser Interface User’s Guide
Section I: Basic Operations 89
Deleting Unicast and Multicast MAC Addresses
To delete a specific static or dynamic unicast or multicast MAC address
from the switch, perform the following procedure:
1. From the Home page, select Configuration.
2. Select the Layer 2 menu option.
3. Select the MAC Address tab.
The MAC Address tab is shown in Figure 19 on page 85.
4. Display the MAC addresses on the switch by selecting one of the
options. For instructions, refer to “Displaying the MAC Address Table”
on page 84.
5. Click on the button next to the MAC address you want to delete from
the switch.
6. Click Remove.
The address is removed from the MAC address table.
Note
You cannot delete the switch’s MAC (CPU) address, an STP BPDU
MAC address, or a broadcast address.
7. To permanently save the change, select the Save Config menu
option.
