AT-S62 Management Software Web Browser Interface User’s Guide
Section I: Basic Operations 87
Adding Static Unicast and Multicast MAC Addresses
This section contains the procedure for assigning a static unicast or
multicast address to a port on the switch. You can assign up to 255 static
MAC addresses per port.
To add a static address to the MAC address table, perform the following
procedure:
1. From the Home page, select Configuration.
2. Select the Layer 2 menu option.
3. Select the MAC Address tab.
The MAC Address tab is shown in Figure 19 on page 85.
4. To add a static unicast address, in the View/Add Unicast MAC
Addresses section, click Add. To add a static multicast address, in the
View/Add Multicast MAC Addresses section, click Add.
The Add MAC Address page is shown in Figure 20.
Figure 20. Add MAC Address Page
5. In the MAC Address field, enter the new static unicast or multicast
MAC address.
6. In the Port Number field, enter the number of the port on the switch
where you want to assign the static address. If you are adding a static
unicast address, you can enter only one port.
If you are entering a static multicast address, you must specify the port
when the multicast application is located as well as the ports where the
host nodes are connected. Assigning the address only to the port
where the multicast application is located will result in the failure of the
multicast packets to be properly forwarded to the host nodes. You can
