AT-S62 Management Software Web Browser Interface User’s Guide
Section VI: Port Security 335
Configuring Authenticator Port Parameters
To configure authenticator port parameters, perform the following
procedure:
1. From the 802.1x Port Access tab shown in Figure 108 on page 330,
click the authenticator port to be configured. You can select more that
one authenticator port at a time. The selected port turns white.
Note
A port must be assigned the authenticator role before you can
configure its settings. For instructions on setting port roles, refer to
“Setting Port Roles” on page 333.
2. Click Settings.
The Authenticator Parameters page is shown in Figure 110.
Figure 110. Authenticator Parameters Page
