Chapter 5: Port Parameters
74 Section I: Basic Operations
If you are configuring a twisted pair port and you select Auto-
Negotiation, which is the default setting, the port’s speed, duplex
mode, and MDI/MDI-X settings are set automatically.
Note the following regarding the operation of Auto-Negotiation on a
twisted pair port:
ˆ In order for a switch port to successfully Auto-Negotiate its duplex
mode with an end-node, the end-node should also be using Auto-
Negotiation. Otherwise, a duplex mode mismatch can occur. A
switch port using Auto-Negotiation will default to half-duplex if it
detects that the end-node is not using Auto-Negotiation. This will
result in a mismatch if the end-node is operating at a fixed duplex
mode of full-duplex.
To avoid this problem, when connecting an end-node with a fixed
duplex mode of full-duplex to a switch port, you should disable
Auto-Negotiation on the port and set the port’s speed and duplex
mode manually.
ˆ If you disable Auto-Negotiation on a port, the auto-MDI/MDI-X
feature on a port is also disabled, and the port defaults to the MDI-
X configuration. Consequently, if you disable Auto-Negotiation and
set a port’s speed and duplex mode manually, you might also need
to set the port’s MDI/MDI-X setting as well.
Here are the possible settings for a twisted pair port:
ˆ Auto: The port uses Auto-Negotiation to set both speed and duplex
mode. This is the default.
ˆ 10Mbps - Half Duplex
ˆ 10Mbps - Full Duplex
ˆ 100Mbps - Half Duplex
ˆ 100Mbps - Full Duplex
Note
Ports 49R and 50R on an AT-8550GB Series switch must be set to
Auto-Negotiation in order to operate at 1000Mbps. You cannot
manually configure these ports to 1000Mbps.
Here are the possible settings for a fiber optic port:
ˆ Half Duplex
ˆ Full Duplex: This is the default setting
