Chapter 13: Access Control Lists
148 Section II: Advanced Operations
Creating an Access Control List
This procedure explains how to create an ACL. Before performing this
procedure, jot down on paper the ID number(s) of the classifier(s) you
want to assign to the ACL and the action of the ACL, which can be either
Permit or Deny. An action of Permit instructs the port to accept packets
from the defined traffic flow of the classifier, while an action of Deny
discards the packets. Having this information handy will make it easier for
you to perform the procedure. To view classifier ID numbers and
specifications, refer to “Displaying the Classifiers” on page 146.
To create an access control list, perform the following procedure:
1. From the Home Page, select Configuration.
2. Select the Network Security menu selection.
3. Select the ACL tab.
The ACL tab is shown in Figure 37.
Figure 37. ACL Tab (Configuration)
The tab lists the access control lists that currently exist on the switch.
The columns in the table are defined here:
ID
The ID number of the ACL.
