Chapter 21: Port-based and Tagged Virtual LANs
302 Secton V: Virtual LANs
Modifying a Port-based or Tagged VLAN
This procedure explains how to add or remove ports from a port-based or
tagged VLAN. When modifying a VLAN, note the following:
ˆ You cannot change the VID of a VLAN.
ˆ You cannot change the name of a VLAN from a web browser
management session, but you can from a local, Telnet, or SSH
session.
ˆ You cannot modify VLANs when the switch is operating in one of the
multiple VLAN modes.
To modify a VLAN, perform the following procedure:
1. From the Home Page, select Configuration.
2. Select the Layer 2 menu selection.
3. Select the VLAN tab.
The VLAN tab is shown in Figure 101 on page 298.
4. Click the button next to the name of the VLAN you want to modify.
5. Click Modify.
The Modify VLAN window for the VLAN is displayed.
6. To add or remove ports from the VLAN, click on the appropriate ports
in the switch image.
Clicking on a port toggles it through the following possible settings:
Untagged port
Tagged port
Port not a member of the VLAN
When assigning ports to a VLAN, note the following:
ˆ If you add an untagged port to the VLAN, the port is automatically
removed from its current untagged VLAN assignment.
ˆ If you remove an untagged port from a VLAN, the port is
automatically returned to the Default_VLAN as an untagged port.
