Chapter 15: Class of Service
178 Section II: Advanced Operations
Mapping CoS Priorities to Egress Queues
This procedure explains how to change the default mappings of CoS
priorities to egress priority queues, shown in Table 6. This is set at the
switch level.
To change the mappings, perform the following procedure.
1. From the Home Page, select Configuration.
2. From the Configuration menu, select the Services menu option.
3. Select the Queuing and Scheduling tab.
Table 6. Default Mappings of IEEE 802.1p Priority Levels to Egress Priority
Queues
IEEE 802.1p Priority
Level
Egress Port Priority
Queue
0 Q1
1 Q0
2 Q0
3 Q1
4 Q2
5 Q2
6 Q3
7 Q3
