AT-S62 Management Software Web Browser Interface User’s Guide
Secton V: Virtual LANs 309
and your remote management of the switches. For this, you would need to
create the NMS VLAN on each AT-8500 Series switch in the enhanced
stack, being sure to assign each NMS VLAN the VID of 24. Next, you
would need to check that the switches in the enhanced stack are
connected together with tagged or untagged ports of the NMS VLAN. You
would also need to specify the NMS VLAN as the management VLAN on
each switch using the management software. Finally, you would need to
be sure that your remote management station is communicating with the
enhanced stack through a tagged or untagged port of the NMS
management VLAN.
Note
You cannot specify a management VLAN when the switch is
operating in a multiple VLAN mode.
To set the management VLAN, do the following:
1. From the Home Page, select Configuration.
2. Select the Layer 2 menu selection.
3. Select the VLAN tab.
The VLAN tab is shown in Figure 101 on page 298.
4. For the Mgmt. VLAN ID parameter, enter the VID of the VLAN on the
switch that is to function as the management VLAN. The VLAN must
already exist on the switch. The default is 1, which is the VID of the
Default_VLAN.
5. Click Apply.
The change in the designated management VLAN is immediately
activated on the switch.
6. To permanently save the change, select the Save Config menu
selection.
