AT-S62 Management Software Web Browser Interface User’s Guide
Section II: Advanced Operations 199
The PoE Port Configuration menu is shown in Figure 57.
Figure 57. PoE Port Configuration Page
The top portion of the page displays the PoE operating status of the
selected ports. The columns are defined here:
Port
Port number.
PoE Function
Whether PoE is enabled or disabled on the port. The default setting is
enabled.
Power Consumed
The amount of power in milliwatts currently consumed by the powered
device connected to the port. If the port is not connected to a powered
device, this value will be 0 (zero).
Power Limit
The maximum amount of power allowed by the port for the device. The
default is 15,400 milliwatts (15.4 W).
Power Priority
The port priority. This can be Critical, High, or Low. The default is Low.
Power Class
The IEEE 802.3af class of the device.
Voltage
The voltage being delivered to the powered device
Current
The current drawn by the powered device.
