Chapter 25: 802.1x Port-based Network Access Control
342 Section VI: Port Security
Displaying the Port-based Access Control Settings
To display port-based access control settings, do the following:
1. From the Home page, select Monitoring.
2. Select the Network Security menu selection.
3. Select the 802.1x Port Access tab.
For definitions of the parameters in the tab, refer to “Enabling and
Disabling Port-based Access Control” on page 330.
4. To view the status of a port, click the port and click Status. You can
select more than one port at a time.
5. To view authenticator or supplicant port access settings, click the port
and click Settings. For definitions of the authenticator parameters,
refer to “Configuring Authenticator Port Parameters” on page 335. For
definitions of the supplicant port parameters, refer to “Configuring
Supplicant Port Parameters” on page 340.
Note
To view the settings of multiple ports, the selected ports must have
the same port role (authenticator or supplicant).
