AT-S62 Management Software Web Browser Interface User’s Guide
Section IV: Spanning Tree Protocols 277
2 - Port Cost
The spanning tree algorithm uses the cost parameter to decide which
port provides the lowest cost path to the root bridge for that LAN. The
range is 0 to 65,535. The default setting is Auto-detect, which sets port
cost depending on the speed of the port. Table 9 lists the STP port
costs with Auto-Detect.
Table 10 lists the STP port costs with Auto-Detect when a port is part of
a port trunk.
6. After configuring the parameters, click Apply.
Table 8. Port Priority Value Increments
Increment
Port
Priority
Increment
Port
Priority
0 0 8 128
1 16 9 144
2 32 10 160
3 48 11 176
4 64 12 192
5 80 13 208
6 96 14 224
7 112 15 240
Table 9. STP Auto-Detect Port Costs
Port Speed Port Cost
10 Mbps 100
100 Mbps 10
1000 Mbps 4
Table 10. STP Auto-Detect Port Trunk Costs
Port Speed Port Cost
10 Mbps 4
100 Mbps 4
1000 Mbps 2
