Allied Telesis AT-S62 - Manual (Page 34)

Chapter 2: Basic Switch Parameters
34 Section I: Basic Operations
Configuring an IP Address and Switch Name
Note
For guidelines on when to assign an IP address, subnet address,
and gateway address to an AT-8500 Series switch, refer to Chapter
3, “Basic Switch Parameters” the AT-S62 Management Software
Menus Interface User’s Guide.
To set basic switch parameters for an AT-8500 Series switch, perform the
following procedure:
1. From the Home Page, select Configuration.
2. Select the System menu option.
3. Select the General tab.
The General tab is shown in Figure 5.
Figure 5. General Tab
