68
Lake Controller Operation Manual Rev 1.5.4
EQ/Levels Menu Reference
Label Function Description
A Parameter Values
For Modules, the value presented in brackets represents the
overall parameter value, which includes any Groups the Module
is assigned to. The bottom value (in the blue box) represents the
value of the Module parameter.
The Group parameter value is shown in the blue edit box.
B Limiter Indicator
Indicates the total RMS and peak limiting gain reduction with an
orange bar that moves downward as gain reduction increases.
C Frame/Module/Group Label
Modules display the selected Module’s name.
Groups display the name of the Module providing metering.
D Fader
Drag the fader up or down to adjust its level. Drag below, above,
or to the left of the fader to adjust by smaller increments.
E Additional Outputs
For a 4-, 5-, or 6-Way/Aux Module, additional output channels
appear here. The number of output channels depends on the
Module type.
F Peak Level / Peak Hold
Indicates peak level with a thin green bar, and peak hold with a
wide orange segment.
G RMS Level Indicator Indicates RMS level with a wide green bar.
H
Input Channel
Label Mute Button
Polarity Button
The channel label is user defined. The color and label of the mute
button identifies the mute status of the channel:
A blue UNMUTED button = channel unmuted
A red MUTED button = channel muted
Modules: A red button with blue text denotes the channel has
been muted by a Group the Module is assigned to. The polarity
button for the channel is located to the right of the mute button.
Groups: An orange button with blue text denotes that at least one
Module in that Group has the channel muted. A red mute button
with blue text denotes the channel is muted on all Modules in the
Group. The polarity button is not available at Group level.
I Input Mixer
Modules only - provides access to the Input Mixer, which allows
audio input channel from available Input Routers to be enabled,
disabled, and mixed as required.
J Input Router Mutes
Modules only - provides access to the Input Router Mutes, which
will affect any Module on a device using selected Input Router.
K Events & Control
Opens a screen containing product specific event logging and
other features (not applicable for MY8-LAKE)
L Levels Menu Button Bar
The functions and submenus available on the Levels screens are
described throughout in this section.
Table 6-1: Function Descriptions for Levels Screen
