Lake Controller Operation Manual Rev 1.5.4
Designer Mode Menu Reference
235
2. Minimize the Controller and, using a text editor (such as Microsoft Notepad), create a text (.txt) file
containing the text you require.
3. Store this text file in the Lake folder in your Windows My Documents directory
e.g. My Documents\Lake\LakeController_vX.XX\Modules\Modules.txt
Since Lake Controller v6.3, user data files are stored
in My Documents\Lake. Or goto Start > All
Programs > Lake Controller vX.XX > User Data Files
for quick consistent navigation across all versions.
Figure 19-11: Storing a Module Help Text File
4. Maximize the Lake Controller and navigate to MODULE STORE/RECALL.
5. Select the Module file example from the scroll bar.
The text you entered appears above the Module as shown in Figure 19-12.
Figure 19-12: Module Help Text
