Lake Controller Operation Manual Rev 1.5.4
Designer Mode Menu Reference
239
Table 19-3: Classic Crossover Types
BESSEL BUTTERWORTH LINKWITZ-RILEY
BE6 BU6 -
BE12 BU12 LR12
BE18 BU18 -
BE24 BU24 LR24
BE30 BU30 -
BE36 BU36 LR36
BE42 BU42 -
BE48 BU48 LR48
19.4.3.3 Linear Phase Crossover Types
The following HPF/LPF types are allowed for Linear Phase 2-Way and 3-Way Module crossover points only
(i.e. not the HPF on the lowest output channel or the LPF on the highest output channel for the Module).
Table 19-4: Linear Phase Crossover Types
LINEAR PHASE
24 dB
LINEAR PHASE
48 dB
LINEAR PHASE
BRICK WALL
LP24 LP48 LPBW
Linear phase crossovers require both sides of the
crossover point to be the same crossover type.
Therefore if the one side of the crossover is
changed, the other side will change automatically.
19.4.3.4 Linear Phase Alignment Delay
Unlike most values in the worksheet, ALIGNMENT DELAY is a Module-based value, not a channel-based
value. Therefore, when ALIGNMENT DELAY is changed for any channel, all other channels of that Module
will be updated automatically.
Linear Phase 2-Way and 3-Way Modules provide six settings: 1.25 ms, 2.5 ms, 5 ms, 10 ms, 20 ms, 40 ms.
Linear Phase Brick Wall 4-Way Modules provide four settings: 3.15 ms, 6.29 ms, 12.58 ms, 25.17 ms.
19.4.3.5 Output EQ Types
Table 19-5 shows the abbreviations for adding output EQ filters via the XOVER - DESIGN worksheet, along
with associated default values.
