210
Lake Controller Operation Manual Rev 1.5.4
Analyzer Plug-in
Figure 18-12: Transfer function measurement mode
The y‐axis scale of the Transfer Function is displayed on the right-side of the Lake Controller interface. The
controls at the top of the Transfer Function display provide easy access to common controls as described
below.
18.4.4.1 Reseed Avg
Reseed Averages clears the averaging buffers (used to increase the stability of the live traces); the trace will
require a short period of time to re-stabilize while the buffers are filled. This function is not available for all
analzyers, or may be automated; please refer to your analyzer documentation for further details.
Changing the number of averages, FFT size, or
sampling rate, or switching between main display
modes, also reseeds the averaging buffers.
