Lake Controller Operation Manual Rev 1.5.4
Designer Mode Menu Reference
221
To lock the base configuration, perform the following steps:
16. Tap MODULES, then tap Module A to select it.
17. Tap LABEL & LOCK. The options shown in Figure 19-3 are displayed.
Figure 19-3: Label & Lock Menu Options
18. Tap SET BASE PASSWORD, type ‘Demo’, and tap OK.
19. Type ‘Demo’ again to confirm, and tap OK to the message.
20. Tap BASE UNLOCKED. This changes to read UNLOCK BASE and the password is now required to
unlock this base configuration file.
The XOVER page will be displayed as VIEW ONLY until it is unlocked. Any user, even a system designer,
cannot adjust the settings without first unlocking the base configuration file.
LEVEL LIMITS and ADJUST FACTORY options are locked out in both User Mode and Designer Mode, and
the input delay fader is removed when in User Mode.
To store the new base configuration file, perform the following steps:
21. Tap LABEL EXIT, then MODULE STORE/RECALL.
22. Tap BASE CONFIGURATION.
23. Navigate to the desired folder location or create a NEW FOLDER.
24. Tap NEW STORE, enter ‘Base Config Test’, and tap OK.
The file is stored in the folder you navigated to prior to storing, and the screen appears similar to Figure 19-4.
Figure 19-4: Storing a Base Configuration File
