Lake Controller Operation Manual Rev 1.5.4
Modules Menu Reference
157
8.6.5.5 New Folder
This button creates a new folder in the current directory.
1. Navigate to the desired directory location and tap NEW FOLDER.
2. Enter the folder name, and tap OK.
8.6.6 Frame Presets
A Frame preset is a configuration for the device stored locally inside the device for fast retrieval from the
Front Panel (not applicable for D Series or MY8-LAKE), Lake Controller or Preset Manager.
There are 100 preset locations available for all Lake-enabled devices, except MY8-LAKE; the MY8-LAKE
card does not support Frame Presets as the host controls all snapshot/preset functionality.
Frame presets can be recalled instantly using the front panel, without the use of the Lake Controller soft-
ware. For further information on presets and Preset Manager functionality, please refer to chapter 27.
The FRAME PRESETS button provides a submenu containing the functions described below.
8.6.6.1 Store
This button is active only when a Module of an online Frame is selected and a preset location is selected
that is not empty (such as when overwriting an existing preset).
To overwrite the settings of the Frame preset:
1. Recall or configure both Modules of the Frame with the required settings.
2. Tap a Module icon of the Frame containing the data you wish to store.
3. Tap FRAME PRESETS from the MODULE STORE/RECALL menu.
4. Select a previously used preset location, and tap STORE.
8.6.6.2 Store with New Name
This button is active only when a Module of an online Frame is selected and a preset location is selected.
The function is similar to STORE, but always provides the on-screen keyboard for entering a preset name.
