304
Lake Controller Operation Manual Rev 1.5.4
Preset Manager
Figure 27-7: Transferring Presets from a Device to a Bank File
In this exmaple, files are copied from the device to the computer (bank file) and will appear in the destina-
tion column as shown on column B in Figure 27-8 once the transfer is complete. Bank file presets can be
transferred in the same way as indicated below.
Figure 27-8: Transferring Presets from a Bank File to a Device
The Exclude Labels setting is set autmatically when
transferring presets between a bank file and an
online frame.
27.4.5 Bank Filename Extensions
Each Lake device has a unique file extension for Bank files as shown in Table 27-1.
