Lake Controller Operation Manual Rev 1.5.4
Modules Menu Reference
127
8.2.3.1 GPI Options and Configuration (LM Series Only)
Table 8-1 lists the options available for General Purpose Input (GPI). These options can be set independently
for a transition from closed > open and from open > closed.
To change the action that occurs for a GPI command:
1. Tap the ‘Acting On’ cell for the required GPI command
2. Select the required option from the pop-up window.
3. Tap the corresponding ‘Action when transistion to CLOSED’ cell
4. Select the required option from the pop-up window that is displayed
5. Tap the corresponding ‘Action when transistion to OPEN’
6. Select the required option from the pop-up window that is displayed
8.2.3.2 GPO Options and Configuration (LM Series Only)
Table 8-1 lists the options available for General Purpose Output (GPO). The state when closed is user-
defined and the state when open is set to the opposite value automatically.
Table 8-1: GPO Options
Indicating State when Closed
Protective Mute State
1. Muted
2. Unmuted
Standby State
1. Standby
2. On
Fault
1. No Fault
2. Any Fault
Ready
1. Ready
2. Not Ready
No Indication -
To change the action that occurs for a GPO command:
1. Tap the ‘Indicating’ cell for GPO1 or GPO2
2. Select the required option from the pop-up window.
3. Tap the corresponding ‘State when CLOSED’ cell
