Lake Controller Operation Manual Rev 1.5.4
Lake Controller Tutorial
47
Figure 4-32: EQ Selector
2. To select a frequency band, tap and drag the selector left or right. To adjust gain of the selected filter,
tap the red rotating X and slide up to boost or down to cut.
If Frequency Lock is off (blue), the frequency can
also be selected and changed by directly tapping
and dragging a yellow X filter point on the EQ
interface.
Figure 4-33: Graphic EQ Screen
3. Tap Filter Flat on the button bar to flatten the selected filter.
Many other features are available on the EQ button bar; please refer to chapter 6 for further details.
4.4.3 Ideal Graphic EQ ™
A unique innovation found in all Lake devices is the Ideal Graphic EQ. Conventional analog and digital graphic
equalizers do not provide intuitive results. For example, pulling up the faders on a conventional graphic equal-
