Lake Controller Operation Manual Rev 1.5.4
Preset Manager
299
27.3.2.4 Rename Preset [F5]
Renames the selected preset on the selected Frames.
If one or more of the selected Frames contains a
different configuration in a particular preset location,
*MISMATCH* displays as the name for that system
preset location.
The RECALL PRESET and RENAME PRESET buttons are disabled when a location is selected for multiple
Frames that contain a preset mismatch.
27.3.2.5 Select Multiple [F6]
Allows the selection of multiple items. Equivalent to holding down [CTRL] on a keyboard.
27.3.2.6 Set Frame Password/Change Password [F7]
Sets or changes the current Frame password.
27.3.2.7 Lock Preset/Unlock Preset [F8]
Presets can be locked to prevent changes or deletion. Locking the first preset on a Frame requires a Frame
password to be set. When a preset is locked, a lock icon is displayed next to it and next to its Frame. Any
further operation on that preset requires the user to enter the Frame password.
Figure 27-4: Online Frame with Locked and Unlocked Presets
In this example, Presets 1+4 are locked, and Presets 2+3 are unlocked. When a Preset is locked, the
Exclude/Include Labels function may be changed without the need to enter a password. Please refer to
Exclude/Inlude Labels section below for further information on this feature.
Unlocking a preset removes its lock but not the associated Frame password.
