Lake Controller Operation Manual Rev 1.5.4
System Store Recall Menu Reference
115
The audio will change quickly, but the Controller will not synchronize with the network until you exit the
SYSTEM PRESET menu. A flashing warning message confirms this.
This enables quick comparison between different configurations without the need to synchronize the
Controller after each preset is recalled
Figure 7-5: System Presets Warning Message
The system configuration name of the preset last recalled will flash at the bottom right of the screen.
Once the required system preset has been recalled, tap HOME or SYSTEM PRESET EXIT to synchronize
the Controller with the new settings that have been recalled into the devices.
Individual Frame presets can also be recalled from
the front panel of each Lake device.
For LM Series devices if the preset recall changes
the configuration between Contour and Mesa
configurations, a warning will be displayed and
Modules returned to the scroll bar.
7.10.3 Quick System Preset Recall and Comparison
Quick Recall mode instantly recalls each system preset into all selected Frames when the preset location
on the scroll bar is tapped. No confirmation messages are displayed while in this mode, and all other preset
functions are disabled.
To enable fast recall/comparison of SYSTEM PRESETS:
1. From HOME, tap SYSTEM STORE/RECALL, then tap SYSTEM PRESETS.
2. Select each Frame you wish to recall the preset into by tapping Module or Groups icons.
Selected Frames are identified by a green icon.
3. Tap QUICK RECALL.
Orange equals active; blue equals inactive.
4. Tap a preset location from the scroll bar.
5. Repeat the previous step to compare with other SYSTEM PRESETS
