Lake Controller Operation Manual Rev 1.5.4
Designer Mode Menu Reference
225
To add GEQ and hide the overlay, perform the following steps:
5. Tap GEQ2.
6. Reduce the 125 Hz filter by 6 dB.
7. Tap EQ OVERLAY HIDE (illuminates orange).
When an EQ overlay is hidden, the effect its filters
have on the overall EQ curve is not visible in User
Mode or when the Module is locked.
To remove an unused channel meter and fader, perform the following steps (not applicable for Mesa EQ):
8. Tap the LEVELS tab.
9. Tap LABEL CHANNEL.
10. Tap the MUTE/LABEL button of output 3.
11. Type ‘unused’, and tap OK.
To lock the Module, perform the following steps:
12. Tap Home, then MODULES.
13. Tap the icon for Module A to select it.
14. Tap LABEL & LOCK, then SET MOD PASSWORD.
15. Type ‘demo’, then tap OK.
16. Type ‘demo’ again to confirm, tap OK, then tap OK to the message.
17. Tap MODULE UNLOCKED.
To store the new Module file, perform the following steps:
18. Tap LABEL EXIT, then MODULE STORE/RECALL.
19. Navigate to the required folder.
20. Tap NEW STORE, type demo Module, and tap OK.
To load this new Module file into Module B, perform the following steps:
