Lake Controller Operation Manual Rev 1.5.4
EQ/Levels Menu Reference
101
6.5.1.4 Four Auxiliary Outputs
The 4-Auxiliary Outputs Module may be recalled into Module A or C. When loading this Module type, and
option to load either the Classic 2-Way or 2-Auxiliary Outputs Module into Module B/D will be provided. No
other combinations are allowed.
6.5.1.5 Five Auxiliary Outputs
The 5-Auxiliary Outputs Module may be recalled into Module A or C. When loading this Module type, the
1-Auxiliary Outputss Module will be recalled into Module B/D. No other combinations are allowed.
6.5.1.6 Six Auxiliary Outputs
The 6-Auxiliary Outputs Module uses two Modules (A&B, or C&D). This Module type can only be recalled
into Module A or C.
6.5.1.7 Classic 2-Way + 1-Auxiliary Outputs
The Classic 2-Way + 1-Auxiliary Outputs Module may be recalled into any Module. The other Modules of
the Frame may contain any Classic or Linear Phase Module that uses two or three output channels.
6.5.1.8 Classic 3-Way + 1-Auxiliary Outputs
The Classic 3-Way + 1-Auxiliary Outputs Module may be recalled into Module A or C. When loading this
Module type, and option to load either the Classic 2-Way or 2-Auxiliary Outputs Module into Module B/D
will be provided. No other combinations are allowed.
6.5.1.9 Linear Phase Brick Wall 2-Way + 1-Auxiliary Outputs
The Linear Phase 2-Way + 1-Auxiliary Outputs Module may be recalled into any Module. The other Modules
of the Frame may contain any Classic or Linear Phase Module that uses two or three output channels.
6.5.2 Using Auxiliary Outputs
To configure a Module for output-specific EQ, first load an Auxiliary Output file into a Module.
1. From Home, tap MODULES.
2. Place Module A of a Frame on the MAIN page, or select an existing Module.
3. Tap MODULE STORE/RECALL.
