Displaying Questionable Data

Questionable data is any data that falls outside defined tolerance
ranges and may be of questionable quality. Perform the following
steps to display questionable data on the scattergraph report:

1. Establish the tolerances using the Scattergraph Editor tool.

See Displaying the Data Tolerance Ranges in Chapter 12 for
more information.

Questionable
Data
button

2. From the Scattergraph Reporter toolbar, select the

Questionable Data toolbar button.

All questionable data points display as blue data points.

Displaying Data Quality

Quality
Range
button

Select the Quality Range toolbar button to display a multi-colored
legend on the scattergraph's Y axis indicating 10 levels of data
quality from 0 to 100%. Each data point on the scattergraph is
assigned a color corresponding to the legend indicating its quality.
As the monitor generates data, it assigns each point a quality
statistic. 0% quality is indicated at the bottom of the legend in red,
and 100% quality is indicated at the top of the legend in green.

Displaying Field Confirmations

Display all field confirmations or a specific time span of
confirmations on the scattergraph. Confirmations display as
diamond symbols; green diamonds indicate included confirmations,
and red diamonds indicate ignored confirmations.

Note: Confirmations can also be viewed in the Quantity
Coefficient Generator tool.
